Juniper JNP-QSFP-100G-LR4Uncategorized

Reliable 100 GbE Long-Range Connectivity for Data Center and Telecom Networks — Juniper JNP-QSFP-100G-LR4

The Juniper JNP-QSFP-100G-LR4 is a high-speed 100 GbE QSFP28 optical transceiver designed for long-range data center, enterprise, and telecom networks. It provides 100 GbE connectivity over single-mode fiber (SMF) with a maximum reach of 10 km, making it ideal for spine-leaf fabrics, ToR uplinks, and core aggregation links.

Key Specifications
Connectivity

• Form Factor: QSFP28 (Quad Small Form-Factor Pluggable)

• Data Rate: 100 Gbps (4×25 GbE lanes)

• Wavelength: 1310 nm

• Fiber Type: Single-mode fiber (SMF)

• Connector Type: LC duplex

• Reach: Up to 10 km over SMF

• Hot-Pluggable: Yes

Performance

• Low Power Consumption: Typically ~4.5 W

• Supports 100 GbE Ethernet, 100GBASE-LR4 standard

• Temperature Range: 0°C to 70°C (operating)

• Compliance: IEEE 802.3ba, MSA QSFP28 standard

• Error-Free Transmission: Supports reliable long-distance connections for enterprise and telecom networks

Use Cases

• Top-of-Rack (ToR) uplinks for high-speed servers

• Spine-leaf data center fabrics with long-range 100 GbE links

• Core and aggregation layer interconnects
