SRX1500-SYS-JB-AC is the SRX1500 Services Gateway includes hardware (16GbE, 4x10GbE, 16G RAM, 16G Flash, 100G SSD, AC PSU, cable and RMK) and Junos Software Base (firewall, NAT, IPSec, routing, MPLS and switching).
Juniper SRX1500-SYS-JB-AC Specification
Model
SRX1500-SYS-JB-AC
Brand
Juniper
Total onboard ports
16x1GbE and 4x10GbE
Onboard RJ-45 ports
12x1GbE
Onboard SFP transceiver ports
4x1GbE
Onboard SFP+ ports
4x10GbE
Out-of-Band (OOB) management ports
1x1GbE
Dedicated high availability (HA) ports
1x1GbE (SFP)
PIM slots
2
Console (RJ-45 + miniUSB)
1
USB 2.0 ports (type A)
1
System memory (RAM)
16 GB
Primary boot storage (mSATA)
16 GB
Secondary storage (SSD)
100 GB
Form factor
1 U
Size (WxHxD)
17.5 x 1.75 x 18.2 in (44.45 x 4.44 x 46.22 cm)
Redundant PSU
1+1
Power supply
AC/DC (external)
Average power consumption
150 W
Average heat dissipation
512 BTU/hour
Maximum current consumption
2.5A (for AC PSU); 6.2A (for DC PSU)
Maximum inrush current
50A by 1 AC cycle
Acoustic noise level
66.5 dBA
Airflow/cooling
Front to back
Operating temperature
32°F to 104°F (0°C to 40°C)
Nonoperating temperature
4°F to 158°F (-20°C to 70°C)
Operating humidity
10% to 90% noncondensing
Nonoperating humidity
5% to 95% noncondensing
Meantime between failures (MTBF)
9.78 years (85,787 hours)
FCC classification
Class A
RoHS compliance
RoHS 2
FIPS 140-2
Level 2 (Junos 19.2)
Routing/firewall (IMIX packet size)
5 Gbps
Routing/firewall (1,518 B packet size)
9 Gbps
IPsec VPN (IMIX packet size)
1.3 Gbps
IPsec VPN (1400 B packet size)
4.5 Gbps
Application visibility and control
7 Gbps
Recommended IPS
4 Gbps
Next-generation firewall
1.7 Gbps
Route table size (RIB/FIB) (IPv4)
2 million / 1 million
Maximum concurrent sessions (IPv4 or IPv6)
2,000,000
Maximum security policies
16,000
Connections per second
90,000
NAT rules
8,000
Media access control (MAC) table size
64,000 (standalone mode)
IPsec VPN tunnels
2,000
Number of remote access/SSL VPN (concurrent) users
2,000
GRE tunnels
2,048
Maximum security zones
512
Maximum virtual router
512
Maximum VLANs
3,900
