Aruba AP‑514 Dual‑Band Wi‑Fi 6 Indoor Access Point
Product Description
The HPE Aruba Q9H57A is the Aruba AP‑514 (RW) — a high‑performance indoor Wi‑Fi 6 (802.11ax) access point from Aruba’s 510 Series, built for enterprise‑grade wireless deployments. It delivers fast and efficient wireless connectivity with support for modern multi‑user environments, making it ideal for offices, schools, campuses, retail, and other medium‑to‑high density indoor spaces.
This model uses dual radios with OFDMA and MU‑MIMO to provide superior throughput and multi‑client performance, with flexible wired connectivity options and support for IoT integration via Bluetooth and Zigbee.
Model Type
Indoor Dual‑Band Wi‑Fi 6 Access Point
Category
Networking – Enterprise Wireless Infrastructure
Key Features
Wi‑Fi 6 (802.11ax) — Dual‑band Wi‑Fi supporting OFDMA and MU‑MIMO for efficient multi‑device traffic handling and higher throughput.
High Peak Data Rates — Up to ~4.8 Gbps in the 5 GHz band and ~575 Mbps in the 2.4 GHz band (≈5.4 Gbps combined).
SmartRate Ethernet — 1× 2.5 GbE SmartRate RJ‑45 and 1× 1 GbE RJ‑45 for high‑speed wired backhaul.
External Antenna Support — Four RP‑SMA external antenna connectors allow use of high‑gain antennas for customized coverage.
Integrated IoT Radios — Built‑in Bluetooth 5 and 802.15.4 Zigbee enable location services and IoT device connectivity without extra hardware.
Advanced Security — Supports WPA3, Enhanced Open (OWE), and Aruba ClientMatch to enhance performance and security.
Flexible Power Options — Powered via PoE (802.3af/at/bt) or direct DC input.
Mounting Ready — Pre‑installed mounting bracket for ceiling or wall mount; compatible with optional mounting kits.
Technical Specs at a Glance
| Specification | Details |
|---|---|
| Model | Aruba AP‑514 (RW) |
| Part Number | Q9H57A |
| Wi‑Fi Standard | IEEE 802.11ax (Wi‑Fi 6) |
| Radios | 2 (5 GHz 4×4 MIMO & 2.4 GHz 2×2 MIMO) |
| Max Data Rate | Up to ~5.4 Gbps combined |
| Ethernet | 1× 2.5 GbE SmartRate + 1× 1 GbE |
| Antennas | 4× RP‑SMA external |
| USB | 1× USB 2.0 Type‑A host |
| Power | PoE (802.3af/at/bt) or DC |
| IoT | Bluetooth 5 & 802.15.4 Zigbee |
| Mounting | Ceiling / Wall (mount bracket included) |
| Dimensions | ~200 × 200 × 46 mm |
| Weight | ~810 g |
Typical Use Cases
Enterprise & Office Networks — Fast and resilient Wi‑Fi connectivity for staff and guest devices.
Education & Campus Deployments — Supports multiple simultaneous wireless clients and rich media.
Retail & Hospitality — Efficient throughput for POS systems, mobile guests, and IoT.
IoT & Location Services — Bluetooth and Zigbee integration enables indoor IoT applications.
