The Cisco PWR-C1-715WAC-P is a 715 W AC-input, hot-plug / redundant power supply module designed to deliver reliable power to enterprise network switches such as the Cisco Catalyst series. It is engineered to support mission-critical switching environments where uptime, resilience, and modular design matter.

Key Features & Highlights

• Power Output & Compatibility
    Delivers –56 V DC at 12.8 A, providing up to 715 W of output power—ideal for PoE or non-PoE Catalyst switches.
    Compatible with Cisco Catalyst 9300 / 9300L / higher scale models and other supported platforms.

• Wide Input Range & Efficiency
    Accepts 100–240 VAC (autoranging) at 50–60 Hz, making it usable globally without voltage conversion.
    Designed for high efficiency and thermal stability in demanding network environments.

• Hot-Swappable & Redundant Design
    Supports hot-plug insertion and redundant module deployment, enabling power redundancy without service interruption.
    Field-replaceable modular form factor ensures easy maintenance and minimal downtime.

• Dimensions & Weight
    Measures approximately 1.58 × 3.25 × 12.20 in (≈ 40.1 × 82.6 × 309.9 mm).
    Weighs about 2.6 lb (1.2 kg).

• Protection & Reliability
    Built-in safeguards: overcurrent, overvoltage, undervoltage, and thermal protection.
    Output holdup time of ~16.7 ms minimum at 100 VAC to maintain stability during transient supply events.

• Operating Conditions
    Ambient operating range: –5 °C to +45 °C (lower temperature conditions for start-up).
    Storage temperature: –40 °C to +70 °C.
    Accepts relative humidity 5–90% non-condensing; supports altitude up to ~10,000 ft (3,000 m) under certain conditions.

• Thermal & Emissions
    Produces approximately 2,445 BTU/hr at full load.
    Complies with EMI/EMC and safety standards for enterprise network equipment.
