eSFP-GE-SX-MM850

Call for Price

The Cisco eSFP-GE-SX-MM850 is a 1 Gbps Small Form-Factor Pluggable (SFP) transceiver module designed for high-speed Gigabit Ethernet and Fiber Channel applications over multimode fiber (MMF). Operating at an 850 nm wavelength, it supports distances up to 550 meters on 50/125 µm MMF. With hot-swappable design, low power consumption, and MSA compliance, the eSFP-GE-SX-MM850 ensures reliable optical connectivity for switches, routers, and media converters. Ideal for data centers, campus networks, and enterprise backbone links, it delivers high performance, durability, and seamless Cisco compatibility.

The Cisco eSFP-GE-SX-MM850 is a hot-swappable Gigabit Ethernet SFP transceiver designed to deliver reliable, high-speed optical connectivity for enterprise and data center networks. Supporting data rates up to 1 Gbps, it operates over multimode fiber (MMF) using an 850 nm wavelength laser, ensuring stable and efficient short-range transmission.

This module enables link distances of up to 550 meters when used with 50/125 µm MMF and up to 220 meters on 62.5/125 µm MMF, making it an ideal solution for intra-building or campus-level connections. It is fully compliant with the SFP Multi-Source Agreement (MSA), ensuring interoperability with a wide range of Cisco switches, routers, and optical networking devices.

The eSFP-GE-SX-MM850 offers Digital Optical Monitoring (DOM) capabilities to track critical parameters like temperature, voltage, and optical power, enhancing network reliability and maintenance efficiency. Designed for energy efficiency and durability, this SFP module helps maintain network uptime while reducing operational costs.

Key Technical Specifications

Model: eSFP-GE-SX-MM850
Form Factor: SFP (Small Form-Factor Pluggable)
Data Rate: 1 Gbps
Wavelength: 850 nm
Cable Type: Multimode Fiber (MMF)
Maximum Distance: Up to 550 m (50/125 µm fiber), 220 m (62.5/125 µm fiber)
Connector Type: LC Duplex
Optical Components: VCSEL Laser and PIN Receiver
Operating Temperature: 0 °C to 70 °C (standard)
Compliance: MSA, IEEE 802.3z (1000BASE-SX)
DOM Support: Yes (Digital Diagnostics Monitoring)
Hot-swappable: Yes

Overview

With robust optical performance and Cisco-certified reliability, the eSFP-GE-SX-MM850 provides a cost-effective, energy-efficient solution for Gigabit Ethernet links in enterprise and service provider environments.
