The Cisco C9300L-24P-4G-E is part of the Cisco Catalyst 9300L Series, the next generation of enterprise-class, stackable access switches built for secure, intelligent networking. Featuring 24 × 10/100/1000 Mbps PoE+ ports and 4 × 1G SFP uplinks, this Layer 3 managed switch provides high-performance connectivity for IP phones, wireless access points, IoT devices, and surveillance systems.
With Cisco IOS XE software, the C9300L-24P-4G-E supports advanced programmability, automation, and security features such as 802.1X authentication, MACsec encryption, and Trustworthy Solutions. It also supports Cisco StackWise-160 technology, enabling up to 160 Gbps stacking bandwidth and simplified centralized management for up to eight switches.
Designed for modern enterprise networks, it offers a PoE+ power budget of 370W, extensive VLAN support, and energy-efficient operation under the IEEE 802.3az standard. This switch is ideal for medium to large organizations, providing scalability, reliability, and security for mission-critical deployments.
⚙️ Technical Specifications
| Specification | Details |
|---|---|
| Model | Cisco C9300L-24P-4G-E |
| Series | Cisco Catalyst 9300L Series |
| Ports | 24 × 10/100/1000 Mbps PoE+ ports |
| Uplink Ports | 4 × 1G SFP |
| Layer Type | Layer 3 Managed |
| Stacking | Cisco StackWise-160 (up to 8 units) |
| Switching Capacity | 104 Gbps |
| Forwarding Rate | 77.37 Mpps |
| PoE Power Budget | 370W total |
| MAC Address Table | 32K entries |
| VLAN Support | Up to 4094 VLANs |
| Security Features | MACsec, 802.1X, IP Source Guard, DHCP Snooping, Dynamic ARP Inspection |
| QoS | 8 queues per port, DSCP/CoS classification |
| Operating System | Cisco IOS XE (Network Essentials License – E) |
| Management | CLI, SNMP, Cisco DNA Center, Web UI |
| Energy Efficiency | IEEE 802.3az compliant |
| Dimensions (H × W × D) | 4.45 × 44.5 × 28.8 cm (1.75 × 17.5 × 11.3 in) |
| Weight | Approx. 5.1 kg (11.24 lb) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Warranty | Cisco Limited Lifetime Warranty |
