ASR1001-XRouter

The Cisco ASR1001-X is part of the ASR 1000 Series Aggregation Services Routers, delivering enterprise-grade scalability, performance, and security. Built for high-speed WAN aggregation and edge routing, it combines powerful hardware with Cisco’s IOS XE software, enabling advanced services such as QoS, firewall, VPN, NAT, and MPLS in a single compact platform.

The router delivers 2.5 to 20 Gbps throughput (upgradeable via software licenses) and is powered by a multicore QuantumFlow Processor (QFP) for high-performance packet processing. It supports modular interfaces, including SFP-based Gigabit Ethernet, 10-Gigabit Ethernet, and SPA interface adapters, allowing flexible connectivity for diverse enterprise needs.

With integrated redundancy, dual power supplies, and hot-swappable components, the ASR1001-X ensures continuous network operation and reliability. It also features integrated hardware encryption and embedded firewall/security services, protecting enterprise networks from evolving cyber threats.

Key Technical Specifications

• Model: Cisco ASR1001-X

• Series: Cisco ASR 1000 Series

• Performance: 2.5–20 Gbps throughput (license upgradeable)

• Processor: Cisco QuantumFlow Processor (QFP)

• Interfaces:

  • 6 × Built-in 1GE SFP ports

  • 2 × Built-in 10GE SFP+ ports

  • 1 × SPA slot for expansion

• Memory: 8 GB default (expandable)

• Storage: 8 GB internal flash + external USB support

• Software: Cisco IOS XE

• Layer Support: Layer 2 and Layer 3 (QoS, MPLS, VPN, NAT, IPv4/IPv6)

• Power: Dual AC power supplies (redundant)

• Dimensions: 1RU (1.72 × 17.3 × 20.0 in)

• Weight: ~18.5 lb (8.4 kg)

Overview

The Cisco ASR1001-X offers carrier-class performance in a compact 1RU design, making it ideal for enterprise WAN edge, aggregation, and service provider deployments. Combining high throughput, scalability, and integrated security, it’s a reliable choice for organizations that demand performance and flexibility
